Product Detail
Specification parameters
| focal length | 16mm | ||||||
| Maximum aperture ratio | 1:2.4 | ||||||
| Maximum screen size | 12.8mmX9.6mm(Φ16mm) | ||||||
| scope of work | aperture | F2.4-F16.0 | |||||
| focus | 0.1m-Inf. | ||||||
| control | aperture | electric | |||||
| focus | electric | ||||||
| angle of view | diagonal | 1″ | 53.2° | 2/3″ | 38.1° | 1/1.8″ | 31.6° |
| level | 43.8° | 30.9° | 25.5° | ||||
| vertical | 33.6° | 23.4° | 19.2° | ||||
| operation temperature | -10°C~50°C | ||||||
| distort | 1″ | 0.0% | 2/3″ | 0.0% | 1/1.8″ | 0.0% | |
| back focal length | 10.7mm（In Air) | ||||||
| Rear flange length | 17.526mm (In Air) | ||||||
| interface | C-interface | ||||||
| filter size | M43 P-0.75mm | ||||||
| weight | 280g | ||||||
| control interface | USB2.0 | ||||||
| Power Mode | USB power supply (500mA) | ||||||
| connector | Type A USB interface | ||||||
