High resolution and high frame rate
Suitable for high-precision detection
-5-604 MP resolution
-GigE, CameraLink, 10GigE, CXP-6, and CXP-12
-Ultra high frame rate for high-speed image capture
ISP algorithm
Uniform and balanced images
Display high-quality images through point by point FFC, shadow correction, automatic exposure, and automatic gain.
Thermoelectric cooling (TEC)
Keep the sensor operating at a stable temperature
TEC is used to ensure low sensor temperature, thereby ensuring low noise levels.
product details
● 10 Gigabit Ethernet interface, providing 10Gbps effective bandwidth;
● The flatness adjustment scheme for patent authorization eliminates virtual focus in the area;
● Excellent heat dissipation design, precise temperature control, maintaining constant temperature;
● 1GB onboard cache is used for data transmission or image retransmission in burst mode;
● Support multiple triggering modes including software triggering, hardware triggering, and free running;
● Support custom ROI, support horizontal mirroring, support vertical mirroring;
● Support ISP functions such as automatic exposure, automatic gain, automatic black level, gamma correction, LUT, etc;
● Black and white cameras support automatic contrast;
● Support point by point FFC correction to provide more uniform image quality;
● Support fan speed adaptive function for setting sensor target temperature;
● Supports DC24V wide voltage power supply, with priority given to 24V;
● Compatible with GigE Vision protocol and GenlCam standard;
● Compliant with CE, FCC, KC, RoHS certifications.
Dimension
Product parameters
|
Basic parameters |
|
| Sensor | IMX253 |
| Sensor type | 1.1″ CMOS |
| Shutter type | Global |
| Resolution | 4096 × 3000 |
| Frame rate | 68 fps |
| Bit depth | 10 |
| Black and white/color | Color |
| Pixel | 3.45 μm × 3.45 μm |
|
Image parameters |
|
| Pixel | 12 MP |
| Signal to Noise Ratio | 39 dB |
| Dynamic range | 71.6 dB |
| Image Format | BayerRG8/10/10Packed, BayerGB8/10/10Packed |
| ROI | support |
| X Flip | support |
| Y Flip | support |
| Gain | 1 ~32 |
| white balance | support |
| gamma | Range 0~4, supports LUT |
| Shutter exposure | 1 μs ~ 15 s |
| Image acquisition mode | Software triggered/hardware triggered/free running |
| SPC | support |
|
Performance parameter |
|
| Configure channels | Support saving custom configurations for 2 groups of users |
| Cache | 1 GB |
| Interface parameters | |
| Interface | 10GigE |
| GPIO Interface | 3-channel optocoupler isolated input, 3-channel optocoupler isolated output; 1 RS232 serial port |
| Lens interface | M58 x 0.75 |
| Power supply parameters | |
| Power supply mode | DC power supply through 12 core Hirose interface, voltage 24V
|
| power consumption | 24 V ≈ 18.7 W |
|
Structure parameters |
|
| Product size | 72 mm x 72 mm x 78 mm (excluding rear shell interface) |
| Net weight | 583 g |
|
Environmental parameters |
|
| Storage temperature | -30℃～+80℃ |
| operation temperature | -30℃～+50℃ |
Spectral Curve
