Product Detail
| Specification | Details |
|---|---|
| Model | 17HF |
| Imager Size | 2/3″ 1/2″ 1/3″ |
| Mount Type | C |
| Focal Length | 16mm |
| Aperture Range | F1.4 – F16 |
| Field of View Angle (Horizontal x Vertical) | 2/3″: 30.9° x 23.2° 1/2″: 22.5° x 16.9° 1/3″: 16.9° x 12.7° |
| Focus Range | 0.29m – ∞ |
| Operation – Focus | Manual with lock |
| Operation – Iris | Manual with lock |
| Filter Size | M25.5 P=0.5mm |
| Wave Length | Visible light |
| TV Distortion | -1.5% ≤ d ≤ 0% |
| Weight | 48g ± 5g |
| Operating Temperature | -10°C – +50°C |
| Motion Range – Focus | 159° |
| Motion Range – Iris | 97° |
| Back Focal Length | 11.85mm |
